Latest Cleanging Trend Durable Solenoid Valve Group Thickening Road Sweeper

3 pieces
MOQ
$42,271.29(3 - 9 pieces) $40,694.01(>=10 pieces)
Precio
Latest Cleanging Trend Durable Solenoid Valve Group Thickening Road Sweeper
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Machine Type: Floor Sweeper
Applicable Industries: Manufacturing Plant, Food & Beverage Factory, Printing Shops, Food & Beverage Shops
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Warranty of core components: 1 Year
Core Components: Deputy engine,draught fan,cluth , Silicone Suc.Ele
Condition: New
Fuel: Diesel
Cleaning Process: /
Dimension(L*W*H): 6800*2275*2700
Warranty: 1 Year
Weight (KG): 8210 kg
Type: Ride-on
Container type: Manufacturing Plant,Food & Beverage Factory,Printing Shops,City roads
Product name: Floor Cleaning Machine
Key word: Floor Cleaner Scrubber
Function: Residue
Application: Cleanging
Name: Electric Road Sweeper Machine
Usage: Widely Used
Keyword: High Suction Power
Key: Vehicle Floor Sweeper
Cleaning width: 1500mm
Información básica
Pago y Envío Términos
Packaging Details: Other
Descripción de producto

Vehicle overview

The washing and sweeping vehicle is modified on the basis of the Dongfeng Euro VI emission, second-class chassis, and is equipped with a sweeping system, a suction system, a water system, a power system, a cabinet, electrical, hydraulic and other systems; it mainly has road cleaning and road surface cleaning. Various functions such as cleaning, curb cleaning, curb and curb facade scrubbing, spray dust reduction, small advertisement cleaning, etc., can be used as a sweeper or a road sweeper, and can also be used as a sprinkler on the road surface Low-pressure flushing; widely used in mechanized cleaning, sweeping, spraying, dust suppression, and cleaning operations in urban roads, highways, airports, docks, corporate factories, and partition squares.When washing and sweeping by the car washing machine, the road surface is cleaned with high pressure and low flow, which is powerful decontamination and efficient water saving. It is especially suitable for the cleaning and cleaning operations of the left and right pavements, curbs and curb facades of urban roads. , Through the suction nozzle to recycle the sewage and garbage generated by cleaning the road surface, it can achieve the effect of no dust, no stains, and no water, and the cleaning can reach more than 97%, which greatly improves the cleaning quality of urban roads.
【整车技术参数】 【Technical parameters of the whole vehicle】
产品名称 product name
HLV5080TXSJX6型洗扫车
HLV5080TXSJX6 washing and sweeping truck
总质量(kg)
Total mass (kg)
8210
罐体容积(m3)
Tank volume (m3)
额定质量(kg)
Rated mass (kg)
1415
外形尺寸(mm)
Dimensions (mm)
6800X2275,2200X2700
整备质量(kg)
Curb weight (kg)
6600
货厢尺寸(mm)
Cargo compartment size (mm)
XX
额定载客(人)
Rated passengers
(person)
准拖挂车总质量(kg)
Total mass of semi-trailer (kg)
驾驶室准乘人数(人)
The number of passengers in the cab (person)
3
鞍座最大载质量(kg)
Maximum load of saddle (kg)
接近角/离去角(°)
Approach angle/departure angle (°)
20/13
前悬/后悬(mm)
Front suspension/rear suspension (mm)
1155/1830
轴荷(kg)
Axle load (kg)
2940/5270
最高车速(km/h)
Maximum speed (km/h)
115
备注：
Remarks:
备注：主要专用装置为箱体,清扫装置,用于路面清扫作业;随底盘选装驾驶室;侧面防护由专用装置代替;
后下部防护装置材料材质:Q235,连接方式:焊接加螺栓连接;后下部防护装置断面尺寸(宽×高):
50×100(mm),离地高度:360mm;ABS系统型号: VIE ABS-II,ABS系统
生产厂家: 浙江万安科技股份有限公司.
Remarks: The main special devices are the box body and the cleaning device, which are used for road cleaning operations; the cab
is optional with the chassis; the side protection is replaced by a special device;
Material of rear lower protective device: Q235, connection method: welding and bolt connection; section size of rear lower
protective device (width × height):
50×100(mm), height from the ground: 360mm; ABS system model: VIE ABS-II, ABS system
Manufacturer: Zhejiang Wanan Technology Co., Ltd.
【底盘技术参数】 【Chassis technical parameters】
底盘型号 Chassis model
JX1083TK26
底盘名称
Chassis name
载货汽车底盘
Truck chassis
商标名称
Brand name
江铃牌 JMC
生产企业
manufacturer
江铃汽车股份有限公司
Jiangling Motors Co., Ltd.
轴数
Number of axles
2
轮胎数
Number of tires
6
轴距(mm)
Wheelbase (mm)
3815
轮胎规格
Tire specifications
7.50R16LT 14PR
钢板弹簧片数
Number of leaf spring
8/8+8,8/3+2,8/4+2,8/5+4,4/8+8,4/3+2,4/4+2,4/5+4,8/6+5,8/5+5,8/8+3,8/4+4,8/4+5,8/5+4,8/4+3,8/3+3,8/3+
前轮距(mm)
Front track (mm)
1680
燃料种类
Fuel type
柴油 diesel
后轮距(mm)
Rear track (mm)
1640,1800
排放依据标准
Emission standard
GB3847-2005,GB17691-2018国Ⅵ
GB3847-2005,GB17691-2018 EuroⅥ
发动机型号
engine model
发动机生产企业
Engine manufacturer
发动机排量
engine capacity
发动机功率
Engine power
JX4D306H
江铃汽车股份有限公司
Jiangling Motors Co., Ltd.
2892
112

Hubei Huilong Special Purpose Vehicle Co.

Hubei Huilong Special Purpose Vehicle Co., Ltd. was established in 2011, is a special purpose vehicle manufacturer. The factory is located in the special vehicle industry cluster in Suizhou, Hubei, China. Hubei Huilong has the strength of independent research and development, production and sales as a whole. Our main products are semi-trailer series, compressed garbage truck series, sweeper series, aluminum alloy transporter series. Our crawler semi-trailer has more than 40 patents and is the key support object of the 13th Five-Year Plan for economic and social development, and the company aims to develop towards specialization, precision, speciality and newness. With the advantages of market research and product innovation, we develop new products every year to meet the real customer needs. The factory has four digital workshops equipped with modern machinery and equipment, including raw material processing workshop, automatic aluminum can body workshop, assembly workshop and painting workshop. Three production lines and 100 sets of special equipment ensure stable and reliable production.
1. Q:Are you a company or a trading company? A:Hubei Huilong special purpose vehicle Co., Ltd. is one of the largest special purpose vehicle manufacturers in China. 2.Q:Where is your factory? A:Our company is located in Suizhou, Hubei, China. 3.Q:How can I get there?   A:We welcome you to visit the factory for inspection. You can go to Tianhe Airport by plane or take high-speed rail to Suizhou Station directly.    4.Q:What are your terms of payment? A: T/T 5.Q:Will you arrange the shipment of the vehicles? A:  Yes, we will arrange shipment according to the trade terms. 6.Q:What is the lead time?   A:20-25 working days.  For other questions, we will reply to you as soon as possible after receiving your email!
